Video Interface for Chrysler MyGig Expand

Video Interface for Chrysler with MYGIG with rear view camera input

Chrysler Chrysler

CI-ZL-MYGIG500-CH

New

Video Interface for  Chrysler with MYGIG

More details

€ 299,00

tax incl.

Video Interface for  Chrysler with MYGIG

The Interface allows to connect a any video-audio-source (e.g. after market DVD player or DVB-T tuner..) to the factory navigation-system, including TV-activation. An additional rear-view camera input switches the video as soon as the reverse gear is activated.

RBZ - RB2  REN - REZ



RER - REW - REP  RHR- RHW - RHP

Product features:

  • Video-insertion
  • 1 NTSC/PAL video-input for after-market devices (e.g. DVD-Player, DVB-T tuner, .)
  • NTSC Rear-view camera video-input
  • Automatic switching to rear-view camera input on engagement of reverse gear
  • Video-in-motion



Compatibility:

ModelRadio / Navigation
200 2011 - 2014MYGIG, RER, RBH, RHR, RBZ,REU, REX, REP, RHP, REZ, REW, REN, RHW, RB2
300 2008 - 2010
Aspen 2008 - 2009
Sebring 2008 - 2010
Town & Country 2008 - 2012



Limitazioni:

Factory RSEMust NOT be installed.
Rear-view cameraOnly compatible to NTSC-video-sources.




Specifications:

Operation voltage
10.5 V – 14.8 V
Stand-by power drain
<1mA
Operation power drain60mA
Power consumption
0.72 W
Video input formats
PAL/NTSC
Temperature range
-30°C to +80°C
Measurements (box only) 70 x 20 x 47 mm (B x H x T)


Remember that in some states it is illegal to use the video in motion while driving!


The manufacturer of this item, and the administrator of this site will not be responsible for any damage to persons or property caused by improper use or in terms contrary to the laws.

CategoryRear View Camera Interfaces, Video integration, Video in Motion
Chrysler200, 300, Aspen, Sebring, Town & Country
